Blaupunkt DOHA 112BT - CD/MP3 Retro Bluetooth Stereo USB AUX Radio

SPECIFICATIONS

• High-End Codem Automotive Tuner
• FM (RDS), AM (MW, LW)
• Heavy Duty Design
• Twin-Encoder concept for fast and comfortable folder/file browsing
• Playback formats: MP3, WMA
• Fast playback from USB
• Selectable display modes (ID3-Tags, folder/ playtime, clock, all mode)
• Data carrier: CD-DA, CD-R, CD-RW, USB
• 9-digit high-grade wide-angle display plus status icons
• Built-in Bluetooth (HFP, A2DP, PBAP, SPP)
• Twin Connect
• Navigation Audio Mix
• Built-in microphone + external mic connector
• Front USB (Standard A-type)
• Rear USB (Standard A-type)
• Front-Aux-in
• Steering wheel control input (programmable)
• 4×50-Watt Max. + 4-channel Preamp-out
• Separate Sub-Out (var. gain/frequency)
• 3-band, semi-parametric Equalizer
• Sound presets (Rock, Pop, Classic)
• X-Bass
• 12 V operating voltage

ANALOG RADIO

• Type of tuner: High-End Codem Automotive Tuner
• World tuner (switchable): EU, Americas, Thailand
• Wave bands: FM1, 2, MW, LW
• Radio Data System (RDS): Alternative Frequency (AF), Clock Time (CT), Enhanced Other Networks (EON), Programme Service Name (PS), Program Types (PTY), Regional Programme (REG), Traffic Announcement (TA), Traffic Program (TP)
• Travelstore: yes (FMT)
• Band Scan / Preset Scan: yes / yes
• Station memory: 25
• Sensitivity: lo / dx
• Interference suppression: yes
• Frequency response (Hz) -3 dB: 30 – 15.000

BLUETOOTH

• Supported version: Bluetooth 2.0 with EDR
• Supported profiles: HFP, PBAP, A2DP, AVRCP, SPP
• Audio streaming: yes
• Pairing (number of devices): 5
• Pairing Code: 1234
• Hands-free calling: via micro + radio speaker
• Hands-free volume: variable
• Microphone: built-in + external mic connector
• Key functions: accept / hang-up / reject call / redial
• Phone book access: yes (up to 1.000 entries by phone)
• Twin Connect: yes (2 simultaneously connected phones for telephony)
• Navigation Audio Mix: yes (Navigation commands via A2DP)
• Auto Wake-Up: yes (radio switched off / ignition on)

DATA CARRIER

• CD: CD-DA, CD-R, CD-RW
• Type disc-drive: Automatic loading
• USB: USB 2.0
• Memory cards: no
• Formatting USB / SD: FAT 32, FAT 16

MEDIA-PLAYER

• Playback format: MP3, WMA
• Title display: ID3-tag (version 2), file, folder
• Folder- & file browsing: yes (w/o track interruption)
• Multiple folder level from MSD: yes
• iPod, iPhone control: yes (via USB)
• Android MP3 control: yes (with operation system Android 2.3 and higher)
• Fast list browsing: yes (via second encoder)
• Display modes: yes (file, folder, song, artist, album, clock, elapsed time, total time, all mode)
• Display of characters: File name up to 50, tags up to 30
• Variable display scrolling: yes (once / always if > 9 digits)
• Mix / Repeat / Scan: yes / yes / yes
• Fast media reading: yes (from USB)
• Bitrate (kBit/s): 32 -320
• Variable bitrates: yes

CD-PLAYER

• Shock Proof Memory: yes
• Frequency response (Hz) –1 dB: 20 – 20.000

EQUALIZER

• Number of bands/ Model: 3 / semi-parametric
• Bass / treble: yes / yes (+/- 7 steps)
• Balance / fader: yes / yes (+/- 9 steps)
• X-Bass: yes
• Sound presets: Rock, pop, classic

AMPLIFIER

• Number of channels: 4
• Max. power: 4 x 50 Watt
• Sinus power at 14.4 V: 4 x 24 Watt

DISPLAY

• Type / Digits: DOT (1-line) / 9
• Angle: Wide view
• Colour: negative, black and white
• Brightness: adjustable
• Clock display: 24 / 12 hrs

INPUTS

• Antenna (number of): 2 (FM ISO)
• USB (number of / type): 2 (front + rear / standard A-Type)
• iPod/iPhone: yes (via front + rear USB)
• Memory cards: no
• Aux-In (number of, type): 1 front (3,5 mm jack)
• Telephone-mute / Line-In: yes / no
• Steering wheel control: yes (analogue programmable)

OUTPUTS

• Loudspeaker (number of): 4
• Pre-amplifier channel: 4-channels (Cinch)
• Pre-amplifier voltage: 4 V
• Variable amplifier delay time: yes
• Sub-Out: yes (Cinch, var. gain/frequency)

GENERAL

• Twin-Encoder concept: Left for volume control & mute Right exclusively for browsing, phone book, tuner & menu
• Software update: via USB
• Variable scan-time: yes
• Confirmation beep: yes (on/off)
• Front panel: Fix panel
• Panel / decor-ring colour: Black / black
• Encoder / key illumination: Blue / Red
• Operation voltage: 12 V
• Permanent preset storage: yes
• Demo mode: yes
• Weight (kg): ca. 1,6
• Height x Width x Depth (mm): 52 x 178 x 170
• IR-remote control: yes
